Cement Filter Socks Aramid Filter Bag Synthetic Fiber Easy Installation CE Certification

China Cement Filter Socks Aramid Filter Bag Synthetic Fiber Easy Installation CE Certification supplier

Large Image :  Cement Filter Socks Aramid Filter Bag Synthetic Fiber Easy Installation CE Certification

Product Details:

Place of Origin: CHINA
Brand Name: RUNNINGFILTER
Certification: CE

Payment & Shipping Terms:

Minimum Order Quantity: 100 PCS
Packaging Details: CARTON
Delivery Time: 20-30 DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000000 PCS PER MONTH
Contact Now
Detailed Product Description
PRODUCT: Cement Filter Socks/nomex Filter Bag/filter Sleeve For Baghouse Type: Dust Filter Bag
Usage: Dust Filter Efficiency: 99.9%
Medium Material: Synthetic Fiber Breathability: Above 10000g/m2.24h

cement filter socks/nomex filter bag/filter sleeve for baghouse



500gsm aramid felt
Material: 100% new aramid fiber
Construction: aramid spun scrim supported
Finish: one side singed & Calender
Hot shrinkage: under 205°C,2 hours,less than 2.5%
Recommended Maximum Continues Operating Temperature: 200°C



Fabric weight: 500 ± 34 g/sq m
Thickness: 2.30 – 2.60 mm
Permeability: 300 – 420 lt/m2*s
Tensile strength – warp / fill: > 700 / 1000 N
Elongation under 3lb strength – warp / fill: < 2% / 2%
Hot shrinkage ( under 205°C, 2 hours): < 2.5%
Treatment: Heat set, singed, Calendered




Four elements of the service life of the filter bag:



I. Select the appropriate filter material

Filter materials should be selected according to the following characteristics:

1. Temperature and humidity of gas and chemical properties.

2. Particle size, weight and shape.

3. Dust concentration

4. Filtration rate

5. Cleaning method

6. Emission concentration

7. The working system of bag filter.

In general, the pulsed spray bag filter is used to select the needle felt, the room is divided into the bag type dust catcher or the mechanical vibration bag filter.



II. Design a reasonable structure

The structure of filter bag should meet the requirement of filter and ash removal of bag filter. To achieve the following points:

1.Easy installation

2.Reliable sealing

3.Pursue the appropriate filtering area and good filtration status.

4.Easy to clean out

5.To avoid wear and tear

6.Coordinate with relevant parts.

7.If the filter bag and frame should be loose fit, the outer filter glass fiber filter bag should be in close cooperation with the small distance vertical reinforcement frame. The filter bag should be considered and set up.



III. Exquisite sewing techniques

1. Advanced technology. The sewing dimension meets the design requirement. And according to the variety of filter material and use temperature, reserved heat shrinkage size.

2. Complete equipment, reasonable stitching distance, no jumping needle, broken line, suture line meets the requirements.

3. The accessories are of high quality, with reasonable coordination, without burr or breakage, and damage the filter bag.

4. The whole filter bag has no holes, jumping yarn, defilement and other defects, and has the proper packaging, not damaged or damped during the storage and transportation. The glass fiber filter bag should not be stressed and stored too long, otherwise it will affect the service life.



IV. Follow the correct way to use it

A. Correct and serious installation:

a. External filter bag installation:

1. The bag mouth and the porous plate are reliably sealed and fixed.

2. The filter bag is suspended vertically under the perforated plate.

3. The adjacent filter bags do not collide with each other.

4. The filter bag and frame are properly matched, and the frame is straight without burr.

b. Internal filtration bag installation.

1. The upper end of the filter bag is fitted with a bag cap and hung from the filter beam by hanging device. Reliable sealing and fixing of lower and lower pockets.

2. The filter bag installation should adjust the tension to reach the regulation value, so that the filter bag will not loosen and fall off when filtering and anti-blowing, and adjust it again after the first week and the first month.



B. Reliable and effective cleaning:

Due to the increasing dust area ash in the filter bag, the pressure difference increases. Therefore, the pressure difference inside and outside of the filter bag should be kept within the set range by effectively cleaning the dust and isolating the dust.



C. Prevent sudden abnormal situation:

The bag-type dust collector should prevent sudden abnormal situation when running. If the gas temperature suddenly increases, or the corrosive gas enters, or the gas temperature drops sharply below the dew point, and so on. Temperature, humidity, chemical causticity, mechanical wear or impact, etc.



D. Equipment maintenance:

The filter bag should be found and replaced if damaged. The pressure difference of bag filter is often observed. In case of ash failure, it is necessary to remove the grey system in time. The process conditions of dust removal system should be adjusted in time to adjust the dust cycle or bag filter work system.



Cement Filter Socks Aramid Filter Bag Synthetic Fiber Easy Installation CE CertificationCement Filter Socks Aramid Filter Bag Synthetic Fiber Easy Installation CE Certification
